Don’t let the classic analog mixer design fool you—the StudioLive® AR12c was built to record. With a pristine analog front-end, eight high-gain XMAX mic preamps, and a 14x4 24-bit, 96 kHz, USB-C compatible USB 2.0 audio interface, its hybrid design makes it simple to record studio productions and mix live shows from a single, intuitive console. Add in a musical 3-band analog EQ, mic/line boost for low-level vintage synths and broadcast microphones, all-new digital effects with rich reverbs and lush delays, Bluetooth® connectivity, and a stereo SD recorder... and you have a mixing and recording powerhouse that fulfills the needs of both modern musicians and content creators.
Recording
14x4 24-bit/96 kHz, USB 2.0 (over USB-C™ connection) audio recording interface
Record every channel plus the main mix
2x2 SD recorder to capture the main mix
Supports SD™ and SDHD™ formats up to 32 GB
Mixing
14-channel analog mixer
8 balanced microphone inputs with XMAX mic preamps
2 insert points
2 instrument/line inputs
12 balanced line level inputs:
4 mono
4 stereo pairs
Stereo Super Channel (Ch. 13/14) with Bluetooth 5.0 input, RCA inputs, 1/8-inch stereo input, and switchable SD/USB stereo playback
4 mono and 4 stereo channels, each with level knob, pan, mute, PFL solo, highpass filter, and 3-band semi-parametric EQ
2 monitor buses with dedicated channel sends, AFL solo, and balanced TRS output
L/R Control Room outputs with level control
Headphone output with level control
Signal Processing
Highpass filter on every channel
3-band quasi-parametric EQ with sweepable mid-band on each mono channel
3-band semi-parametric EQ on each stereo channel
Stereo effects processor with 16 presets, dedicated send and return, and bypass footswitch jack
Mic/line boost on stereo channels for low-level input sources and consumer devices
Included Software
Capture™ live multitrack recording software
Studio One ® Artist recording and production software (DAW)
Studio Magic plug-in suite
Power
Internal power supply
Standard IEC power connector
Physical
Sturdy metal construction
60 mm faders
Optional rackmount kit
