Product details
OVERVIEW
The SUB 702-AS mk3 is a portable 12" high-power active subwoofer for live sound applications. It features a state-of-the-art transducer with a high-power ceramic magnetic circuit and a powerful Class-D amplifier that delivers sound pressure levels up to 129 dB with exceptional headroom. Designed as the ideal complement for 8" or 10" loudspeakers, it provides outstanding performance in any application. Rear panel controls include volume, EQ, polarity, and crossover frequency selection. The rugged all-wood cabinet with scratch-resistant polyurea coating makes it durable, easy to carry and install securely. With its versatility, sound quality, and high power output, the SUB 702-AS MK3 is perfect for small to mid-sized venues and portable applications.
FEATURES
1400 Watt Class-D Amplifier
12” Woofer, bass reflex housing
Stereo Crossover
Switchable Crossover Frequencies
Polarity-reverse switch
Electronic equalization, soft limiter and protection
Stereo XLR input, Stereo XLR signal output
Bass Motion Control excursion management
Lightweight - 21.5KG
SPECIFICATIONS
TECHNICAL SPECIFICATIONS Acoustical specifications Frequency Response 40 Hz ÷ 120 Hz Max SPL @ 1m 129 dB Transducers Woofer 12'', 2.5'' v.c Input/Output section Input signal bal/unbal Input connectors XLR Output connectors XLR Input sensitivity-2 dBu/+4 dBu Processor section Hi-Pass Frequencies 110 Hz Low-Pass Frequencies 80 Hz Protections Thermal, RMS Limiter Soft Limiter Controls Volume, EQ, Phase, Xover Power section Total Power 1400 W Peak, 700 W RMS Low frequencies 1400 W Peak, 700 W RMS Cooling Convection Connections VDE Standard compliance Safety agency CE compliant Physical specifications Cabinet/Case Material Baltic birch plywood Handles One each side Pole mount/Cap M20 thread Grille Steel with clothing Color Black Size / Weight Height 523 mm / 20.59 inches Width 360 mm / 14.17 inches Depth 515 mm / 20.28 inches Weight 21.5 kg / 47.4 lbs
