Flexibility, power, and compactness make the RCF TT 515-A ideal for installed and portable professional applications where size and weight are critical factors. This approach combines the advantages of TT+ technology such as controlled dispersion, outstanding clarity and extreme power, multiple flexible rigging accessories, weatherproof protection, and RDNET real-time monitoring and management software with recallable presets. Its transducer configuration pairs two custom-loaded 5-inch cone drivers to a rotatable CMD waveguide surrounding a titanium 1.75-inch high-frequency compression driver. Whether it’s used as a compact main system, as fills, or surrounds in a larger system, TT 515-A is quick to deploy and fast to tune.
TT515A can be used with TT808-AS subwoofers for applications requiring sub-bass reproduction.
127 dB max SPL
100° x 70° coverage
LF 2 x 5" neodymium woofer, 2” voice coil
HF 1.75” titanium comp. driver
2 x Class-D amplifiers, 1000 Watts RMS total power
70 – 20.000 Hz frequency range
RDNet on board
FiRPHASE and Bass Motion Control
